NICHICON Adds 2.5V-Rated Models to the PCL Series of Chip-Type Conductive Polymer Aluminum Solid Electrolytic Capacitors with Long Life and Reliability

2020-10-14 | Return

NICHICON CORPORATION expanded the voltage range of the PCL series (chip-type conductive polymer aluminum solid electrolytic capacitors) originally launched in October 2018 to include 2.5V, this brings the PCL series voltage range from 2.5V to 25V. These products guarantee 20,000 hours of operation at 105°C. This is the longest endurance rating in the industry.

The new series will be exhibited at CEATEC 2020 ONLINE, held from Tuesday, October 20, to Friday, October 23.

Overview and Development Background
Conductive polymer aluminum solid electrolytic capacitors, which use conductive polymer electrolytes, feature superior equivalent series resistance (ESR) characteristics at high frequencies and excellent allowable ripple currents. IoT devices and communication infrastructure equipment has expanded in recent years, driven by IoT integration in home electronics and 5th generation mobile communication (5G) technologies.

Circuit drive voltages are broadening with the diversification of electronic devices. There are demands for reductions in the maintenance of communication infrastructure equipment as the trend toward using such equipment over a longer period of time increases. In response to the market need for capacitors in a wide range of voltage ratings, NICHICON added a 2.5V-rated model to its lineup of the PCL series (chip-type conductive polymer aluminum solid electrolytic capacitors with long life and reliability).

Features
NICHICON enhanced its conductive polymer aluminum solid electrolytic capacitor technology and further optimized the raw materials and material design to produce the additions to the PCL series. Customers now have a wider range of voltages to choose from, helping them in reducing the frequency of maintenance and lengthens the life of their products.

Main Specifications
Note: Figures in parentheses indicate ratings for the newly added model.

> Rated voltage range: 2.5 to 25 V DC (2.5 V)
> Rated capacitance range: 12 to 3300 μF (270 to 3300 μF)
> Category temperature range: -55 to +105°C
> Product dimensions: φ5×6L, φ10×12.7L (mm) (seven sizes) , φ5×6L, φ10×12.7L (mm) (five sizes)
> Life: 20,000 hours at 105°C
> Terminal shape: Chip type
> Samples: From October 2020 (newly added model)
> Mass production: From December 2020 (newly added model)
[Planned production volume: 1 million/month]
> Production plant: NICHICON (OHNO) CORPORATION, SITE II Factory 4-24-15 Technology Center, Tsuchifugo, Ono, Fukui Prefecture
(ISO 9001, IATF 16949, and ISO 14001 certified)

Source：http://www.nichicon.com/
