Abracon Releases Power-Optimized AX5 ClearClock™ Oscillators with Ultra-Low Jitter of 125fs

2019-05-23 | Return

Abracon announces the availability of the ClearClock™ AX5 ultra low jitter oscillator with 125fs typical jitter. The AX5 marks the latest addition to the ClearClock™ product family and targets space constraint applications requiring a 3.2x5mm footprint. It supports high data rate and high bandwidth applications such as networking, communications, RF, test and measurement, base stations, switches, routers, storage and cloud computing delivering 25Gbps to 400Gbps data links.

Phase-locked loop (PLL) oscillators with low jitter performance consume high amounts of power. The ClearClock™ series offers the lowest power consumption in its class supporting power supply voltages of 3.3V, 2.5V and 1.8V while consuming as little as 130mW of power.

“Industry leading low-power consumption in a smaller package is what the networking and high-performance industry needs,” said Juan Conchas, director of marketing with Abracon. “The need to manage heat dissipation cannot be traded off against bandwidth. Customers require continuous optimization of both phase jitter and bandwidth as well power consumption particularly as device footprints shrink.”

The AX7 offers the same technology in a 5x7mm footprint. Ideally suited for high performance clocking, the series covers frequencies from 50MHz to 2.1GHz while supporting the most common output logic types like LVPECL, LVDS, CML and HCSL. Standard +/-50ppm and +/-100ppm and other stability options are supported with an operating temperature range of -40˚C to 85C.

The ClearClock™ family is now in stock and non-stocked frequencies are available for sampling with a short lead time.
