NICHICON Launches Industry´s Longest Life PCM Series of 125℃ Chip-Type Conductive Polymer Aluminum Solid Electrolytic Capacitors

2020-04-21 | Return

NICHICON CORPORATION has launched the PCM series (chip-type conductive polymer aluminum solid electrolytic capacitors) for automotive applications and industrial equipment requiring a high degree of reliability. At a guaranteed 8,000 hours of operation, the PCM series features the longest life rating in the industry for capacitors rated at 125°C. The PCM series retains the characteristics of the PCR series (4,000 hours guaranteed at 125°C), such as the same capacitance and ESR, while achieving a longer life (8,000 hours guaranteed at 125°C).

Overview and Development Background
Integration and diversification of control boards is progressing in the automotive industry accompanying technological progress in automotive onboard electronics such as those supporting ADAS* and self-driving features. High temperature heat-resistant components are required as a result of changes such as having powertrain ECUs** installed in the engine compartment. In addition to being heat resistant the capacitors must also be long-lasting. To meet these needs, Nichicon developed the PCM series to be heatresistant while having long life.

Features
The PCM series further advances the high-heat-resistance technology of conductive polymer aluminum solid electrolytic capacitors. The PCM series achieves longer life than the PCR series while maintaining characteristics such as capacitance and ESR by further improving the conductive polymer formation methods, optimizing material composition and material design, and increasing the sealing performance. As a result, this will contribute to further expand temperature ranges and miniaturization leading to a reduction in production costs and allowing our customers to choose from a broader range of capacitors to meet their needs.

Main Specifications
> Rated voltage range: 16 to 80 V DC
> Rated capacitance range: 12 to 1000 μF
> Product dimensions: Φ6.3×6L to φ10×12.7L (mm) (eight sizes)
> Category temperature range: -55 to +125°C
> Life: 8,000 hours at 125°C (Φ6.3: 6,000 hours at 125°C)
> Terminal shape: Chip type
> Samples Currently available
> Mass production: From April 2020
[Planned production volume: 1,000,000/month]
> Production plant:
NICHICON (OHNO) CORPORATION,
SITE II Factory
4-24-15 Tsuchifugo, Ono, Fukui Prefecture
(ISO 9001, IATF 16949, and ISO 14001 certified)

Terminology Explanation
*ADAS: Advanced driver- assistance systems
**ECU: Electronic Control Unit

PCM Series of 125°C Chip-Type Conductive Polymer Aluminum Solid Electrolytic Capacitors
