NVE Introduces Smart I²C TMR Angle Sensor

2020-02-03 | Return
EDEN PRAIRIE, Minn.—February 3, 2020—NVE Corporation today expanded its industry-leading line of angle sensors with the new ASR012-10E Smart I²C TMR Angle Sensor.

The ASR012 is based on the same TMR sensor element and digital processing core as the popular ASR002, but with an Inter-Integrated Circuit (I²C) rather than a Serial Peripheral Interface (SPI). The new part also provides a pulse-width modulated (PWM) output.



Advanced Technology
Both the ASR012 and ASR002 have precise, factory-calibrated Tunneling Magnetoresistance (TMR) sensor elements, and sophisticated digital signal processing.

Exceptional Features:

Key ASR022 and ASR002 features include:
• Factory calibrated
• 0.1 degree resolution
• 0.2 degree repeatability
• Robust 6 to 20 millitesla magnetic field operating range
• Fast 12.5 kilosamples per second sample rate
• Flexible 2.2 to 3.6 volt supply range
• Low 4 milliamp typical supply current
• Wide -40 to +125 degrees Celsius operating range
• Ultraminiature 2.5 by 2.5 by 0.8 millimeter package

Available Now
Sensors and evaluation kits are available now for immediate delivery. The ASR012-10E sensor is priced at $2.22 each in 1000-piece quantities.

Evaluation Kit
The ASR012 Evaluation Kit (part number AG963-07E) includes a magnet assembly, magnet fixturing, and PC-based user interface software. Kits are priced at $195 each.

More Information
Click here to download the ASR012 datasheet, or visit www.nve.com for more information.
